CNC Press Brake (350 TOn)

---

The CNC press brake uses a electro-hydraulic system to control the cylinder synchronization. It features high precision synchronization, high bending accuracy, and high repeat positioning accuracy.

The press brake can be used for many different forming jobs with the right die design.

• V-Dies - most common
• Rotary Bending Dies - cylindrical shape with 88-degree V-notch cut on axis
• 90 Degree Dies - used for most bottoming operations
• Acute Angle Dies - "air-bending" used to produce acute, 90-degree, and obtuse angles
• Gooseneck Dies - "return-flanging"
• Offset Dies - "Z shape"
• Hemming Dies - two stage dies combining an acute angle
• Seaming Dies - seams in sheets and tubes
• Radius Dies - a radiused bend
• Bending Dies - "stopped rib" feature that stiffens the resulting part
• Curling Dies - curled or coiled edge on the sheet
• Tube/Pipe Forming Dies - roll up or curling
• Four-way Die Block - block that may have a V machined into four sides
• Channel-Forming Dies - a punch pressed into a die to form two angles at the bottom of the sheet
• U-Blend Dies - similar to channel forming, but with rounded bottom
• Box-Forming Dies - simple angle bends on each side
• Corrugating Dies - wavy surface
• Multiple-Bend Dies - shape forming several bends on a single stroke of the press
• Rocker-Type Dies - rocker insert allowing side-to-side motion
